Description

USB to UART TTL Serial Cable (PL2303HX)

This USB serial cable supplies +5V at up to 500mA (USB specification limit) along with TxD and RxD signals no hardware handshaking. It is very easy to use you just need to plug it into the computer there will be a com found in the computer. Then you Open the serial tester to test the Serial Data.

Note: The USB to serialport chip PL2303HX does not support Win 10.

Specifications:

• Provides 4wire 5V TTL serial interface. Wire color coding as follows
  • Red: +5V
  • Green: Tx
  • White : Rx
  • Black: GND

• Wire length: 90cm
