1N4734A 5.6V Zener Diode

Description

This1N4734A Zener diodeis another form of diode which comes in Through-hole package. Zener diode will mostly be used in a protection circuit or in acrude voltageregulator circuit. Either way, it very important to remember that a Zener diode should always be used along with aZener resistor.The 1N4734A 5.6V Zener Diode has a nominal voltage of 5.6V and like other types of Zener diodes, it can be used as a reference element in voltage regulation, and it can also be used in switching applications and clipper circuits.

Equivalent to the 1N4734A 5.6V zener diode, other zener diodes including the10V zener,9.1 zener,8.2 zener, 7.5 zenerand6.8 zenercan be found from the website.

Features of the 1N4734A 5.6V Zener Diode

• Package type : Through hole
• Nominal Voltage : 5.6V
• Tolerance : 5%
• Power Dissipation : 1.0 Watt
• Storage Temperature : -65 to 175 degree C
• Weight : 0.35g
• Case type : Do-41 Glass Case
• High reliability
• Very sharp reverse characteristics.

Mechanical Drawing of 1N4734A 5.6V

Package Includes

1 x1N4734A 5.6V Zener Diode
