Aluminum Heatsink with Fan for Jetson Orin NX/Orin Nano/Xavier NX Module, PWM Speed Control, 583916.25 mm

Aluminum Heatsink with Fan for Jetson Orin NX/Orin Nano/Xavier NX Module, PWM Speed Control, 583916.25 mm

Original price was: $29.99.Current price is: $17.99.

SKU: BVHB1865361785 Category:

Description

Overview

Aluminum Heatsink with Fan for Jetson Orin NX/Orin Nano/Xavier NX Module provides active air cooling to keep module temperatures low and prevent overheating or throttling under high-load edge computing tasks. The all-aluminum heatsink is designed for continuous deployment and supports PWM fan speed control. It is compatible with reComputer J401 board official.

Key Features

  • Compatible with NVIDIA Jetson Orin NX, Orin Nano, and Xavier NX modules
  • Active cooling with integrated fan; effective thermal management using full aluminum alloy heatsink
  • PWM control for customized air-flow speed
  • Convenient installation with mounting holes; screws included
  • Designed for sustained operation to reduce thermal throttling

Specifications

Material Full aluminum alloy heatsink with integrated fan
Compatibility Jetson Orin NX / Orin Nano / Xavier NX Module
Overall dimensions (drawing) 57.60 0.25 mm 39.60 0.25 mm 16.25 0.25 mm
Front view dimensions (photo) 5.8 cm 3.9 cm
Cable length (110 10) mm
Mounting hole pattern 28.70 0.15 mm (W) 43.30 0.15 mm (H)
Mounting holes 4 M2.0, depth 4.5; additional 4 3.2
Fan speed control PWM

Whats Included

  • Aluminum Heatsink 1
  • Heatsink compounds 1
  • Heat Sink holder 1
  • Screws 4

Applications

  • Cooling NVIDIA Jetson Orin NX / Orin Nano / Xavier NX modules

Manuals

  • Datasheet

Certification

HSCODE 8414599060
USHSCODE 8473305100
EUHSCODE 8414591500
COO CHINA

Details

Jetson Orin cooling fan dimensions: 57.6639.60110 mm, with mounting holes, M2.0 screws, and precise tolerances for secure fit.
