Axisflying Firefly 1800TVI Analog Night Vision Drone Camera, Sony 1/3'' CMOS, CVBS, WDR, F1.2/0.01Lux, 540V

Axisflying Firefly 1800TVI Analog Night Vision Drone Camera, Sony 1/3” CMOS, CVBS, WDR, F1.2/0.01Lux, 540V

Original price was: $33.00.Current price is: $19.80.

SKU: BVHB1865361948 Category:

Description

Overview

The Axisflying Firefly camera is an analog night vision drone camera designed for FPV systems. It delivers 1800TVI horizontal resolution via a CVBS video signal, supports wide 540V input, and uses a Sony 1/3″ CMOS sensor for stable imaging in low light.

Key Features

  • Low illumination performance: F1.2/0.01Lux
  • Low latency analog output
  • Wide operating voltage: 540V
  • WDR (Wide Dynamic Range)
  • PAL/NTSC switchable; 16:9 or 4:3 aspect selectable

Specifications

Sensor Sony 1/3″ CMOS Sensor
Horizontal Resolution 1800TVI
Pixel Size 3.75m
Image Aspect Ratio 16:9 / 4:3 Selectable
Video Format PAL/NTSC Switchable
Field of View (FOV) H100 / V70
Electronic Shutter Auto
Low Light Sensitivity F1.2/0.01Lux
White Balance Auto
Operating Voltage 5V-40V
Noise Reduction 3D
Day/Night Mode COLOR
Menu NO
Input voltage 5V-40V
Operating Temperature -20-70
Dimensions 19mm*19mm
Module Dimensions 29.7mm19mm19mm
Operating Current 130mA@12V
Weight 8.5g

Pinout

1 POWER DC 5~40V
2 GND OSD
3 CVBS CVBS video signal
4 OSD OSD
5 OSD OSD

Wiring and OSD

  • Power: DC 540V; GND; Video out (CVBS); OSD connector.
  • Short press the middle button on the menu board to enter OSD settings.
  • Coaxial cable and analog interface cannot be connected and operated simultaneously.

Applications

For FPV and small UAV builds that require an analog CVBS drone camera with strong low-light capability and wide input voltage.
