Bambu Lab PPS-CF Filament 1.75mm 750g

Description

PPS-CF is a composite material made from carbon fibre-reinforced polyphenylene sulfide. The combination of PPS resin and carbon fibre gives PPS-CF exceptional properties, including excellent resistance to solvents, corrosion, heat, and flames. Additionally, it offers superior strength, stiffness, and dimensional stability, making it a specialised engineering plastic that meets the demands of unique and challenging applications.

Ultra-High Heat Resistance

PPS-CF boasts a heat deflection temperature of up to 264C under 0.45 MPa and can continuously operate at temperatures exceeding 200C. This significantly outperforms normal PA-CF materials, which have maximum temperatures around 190C and 120C. Its exceptional heat resistance ensures outstanding creep resistance, making PPS-CF ideal for demanding industrial environments and applications.

Filament Type	PLA Basic	ABS	PC	Normal PA-CF	PA6-CF	PET-CF	PPA-CF	PPS-CF
Heat Deflection Temperature / (0.45 MPa)	57	87	117	184	186	205	227	264

Superior Flame Retardancy

PPS-CF achieves a UL-94 V-0 flame retardant rating, offering superior safety and reliability in critical areas such as electronics and automotive components. PPS-CF provides long-lasting durability and peace of mind even in the most demanding environments.

Unmatched Mechanical Properties

Combining the stiffness of PPS polymers with the reinforcing power of carbon fibre, PPS-CF offers exceptional stiffness, bending strength, and tensile strength. Its superior dimensional stability and resistance to warping ensure that large-scale prints maintain precision and avoid deformation during the printing process, making it perfect for high-precision applications.

	PET-CF	PPS-CF	Improved %
Stiffness (Bending Modulus – XY, Dry State)	5320 MPa	7160 MPa	34.59%
Strength (Bending Strength – XY, Dry State)	131 MPa	142 MPa	8.40%

Solvent and Chemical Resistance

PPS-CF offers outstanding solvent and chemical resistance, second only to PTFE (Teflon). It remains virtually insoluble in any solvent below 200C and exhibits exceptional resistance to acids, bases, and salts under normal conditions. This makes PPS-CF the ideal choice for challenging environments where chemical stability is critical.

Ultra-Low Water Absorption

With an extremely low moisture absorption rate of just 0.05%, PPS-CF ensures that its mechanical and thermal properties remain stable even in humid conditions. Unlike normal PA-CF, which can soften and degrade when exposed to moisture, PPS-CF maintains its strength and durability, making it the superior option for applications requiring high moisture resistance.

Parameters Comparison

	PPS-CF	PET-CF	PA6-CF
Composition	Polyphenylene sulfide (PPS), Carbon Fiber	Polyethylene terephthalate (PET), Carbon Fiber	Nylon6 (PA6), Carbon Fiber
AMS & AMS lite Compatibility	Not Compatible	Not Compatible	Not Compatible
Dry before Use	Required	Required	Required
Sealed during Printing	Sealed with desiccant	Sealed with desiccant	Sealed with desiccant
Printer Type	Enclosed	Enclosed (Recommended) / Open-frame	Enclosed
Nozzle	Hardened Steel 0.6 mm (recommended) / 0.4 mm / 0.8 mm	Hardened Steel 0.6 mm (recommended) / 0.4 mm / 0.8 mm	Hardened Steel 0.6 mm (recommended) / 0.4 mm / 0.8 mm
Nozzle Temperature	310 – 340	260 – 300	260 – 300
Bed Temperature	100 – 120	80 – 110	100 – 110
Toughness (Impact Strength – XY, Dry State)	27.8 kJ/m	36.0 kJ/m	40.3 kJ/m
Toughness (Impact Strength – XY, Wet State)	27.8 kJ/m	37.3 kJ/m	57.2 kJ/m
Strength (Bending Strength – XY, Dry State)	142 MPa	131 MPa	151 MPa
Strength (Bending Strength – XY, Wet State)	142 MPa	127 MPa	95 MPa
Layer Strength (Bending Strength – Z, Dry State)	36 MPa	49 MPa	80 MPa
Layer Strength (Bending Strength – Z, Wet State)	36 MPa	46 MPa	45 MPa
Stiffness (Bending Modulus – XY, Dry State)	7160 MPa	5320 MPa	5460 MPa
Stiffness (Bending Modulus – XY, Wet State)	7160 MPa	5240 MPa	3560 MPa
Layer Adhesion (Impact Strength – Z, Dry State)	2.8 kJ/m	4.5 kJ/m	15.5 kJ/m
Heat Resistance (HDT, 0.45 MPa, Dry State)	264	205	186
Saturated Water Absorption Rate (25 C, 55% RH)	0.05%	0.37%	2.35%

Accessory Compatibility

	Recommended	Not Recommended
Build Plate	Smooth PEI Plate / Textured PEI Plate	Cool Plate
Hotend	Hardened Steel 0.4mm / 0.6mm (recommended) / 0.8 mm	Hotend with Stainless Steel Nozzle (all size) Hotend with Hardened Steel Nozzle (0.2 mm)
Glue	Bambu Glue Stick	Bambu Liquid Glue
AMS & AMS lite	/	AMS & AMS lite

Recommended Printing Settings

• Drying Settings before printing: 100 – 140 C, 8 – 12 h
• Printing and keeping container’s humidity: < 20% RH (Sealed, with Desiccant)
• Nozzle Temperature: 310 – 340 C
• Bed Temperature (with glue): 100 – 120 C
• Printing speed: < 100 mm/s
• Chamber temperature: 60 to 90C

Physical Properties

• Density: 1.26 g/cm
• Vicat softening temperature: 268 C
• Heat deflection temperature: 264 C
• Melting temperature: 264 C
• Melt index: 11.48 1.23 g/10 min

Mechanical Properties

• Tensile strength: 87 5 MPa
• Breaking elongation rate: 1.2 0.4 %
• Bending modulus: 7160 280 MPa
• Bending strength: 7160 280 MPa
• Impact strength: 27.8 2.3 kJ/m

Includes

• 1x Filament with cardboard spool + desiccant
