Blackmagic Design Fan – DeckLink 4K Extreme 12G

Description

Blackmagic Design Fan – DeckLink 4K Extreme 12G

The Blackmagic Design DeckLink 4K Extreme 12G is an 8-lane PCIe Gen2 digital cinema capture and playback card with two multi-rate 12G-SDI inputs and outputs that accept resolutions from SD up to DCI 4K (4096×2160) at 60 fps. The card supports 10-bit YUV and 8-, 10-, and 12-bit RGB colour, as well as up/down/cross conversions and 3D stereoscopic output at full bandwidth 4:4:4:4 RGB. The DeckLink 4K Extreme 12G features a mezzanine card design that has 4K HDMI input and output connectors on a second daughter card, along with connections for adding two optional optical fibre modules for Dual Link optical fibre SDI input and output. The card also supports AES/EBU balanced XLR and unbalanced RCA inputs/outputs, analog video I/O, reference input, and RS-422 control via an included breakout cable.

Features:

8-Lane PCIe Gen2 I/O Card

Multi-Rate 12G-SDI and HDMI Connections

Supports UHD 4K and DCI 4K Up to 60 fps

Single & Dual Link 4:4:4:4/4:2:2 Signals

3D Stereoscopic SDI Output at 4:4:4:4

Up/Down/Cross Conversion

Optional Optical Fiber I/O Modules

Breakout Cable for Analog / RS-422

Genlock & Deck Control

Compatible with Mac, Windows, and Linux
