DJI H30TZenmuse Series

Key Features

• Upgraded Thermal Sensor:1280 x 1024 resolution – improved by 4x. 32x digital zoom. Supports zoom and infrared and simultaneous split-screen display.

• Improved Visual Zoom:40MP camera with 400x digital zoom and 34x optical zoom and optimised stabilisation.

• High-res Video:The wide-angle and zoom cameras support 4K UHD @ 30fps.

• Wide-angle Camera:48MP 1/1.3-inch CMOS sensor.

• Laser Rangefinder:Enhanced range of up to 3,000m, with an accuracy of 0.2 m under 500m and 1m over 500m.

• NIR Auxiliary Light:Light up dark environments up to 100 metres away using NIR bands.

• Detect Details:Superior observation effect on target details 700m away compared to the H20 Series.

• Multi-Touch Gesture:Easily manage the camera features using the touchscreen settings on the DJI RC Plus Controller.

• Night Vision:Activate night mode with the options of full-colour or black-and-white to achieve higher clarity and accuracy in low-light environments.

• Weather Resistant:IP54 rated and handles temperatures from -20 to 50C.

• Drone Compatibility:Deploy with the DJI M350 RTK, or the DJI M300 RTK when using the DJI RC Plus.

Upgraded Thermal Camera

Enhanced Infrared Data

• 1280 x 1024 Infrared Resolution:The thermal camera’s 1280 x 1024 is 4x better than the H20T. It also has 32x digital zoom. Ultra-High Resolution Infrared Image function ensures images remain clear at higher zoom levels.

• New High-Res Mode:H30T supports three infrared gain modes. High Gain mode provides precise temperature measurements; Low Gain mode enables a wider temperature range; and High-Res mode is ideal for observing things with small temperature differences.

• Visual and IR Cameras Simultaneous Zoom:The zoom and thermal cameras support Link Zoom – which scales the RGB and thermal images in tandem to maintain the same viewpoint.

• Wide Temperature Range:Use the infrared density filter (available separately) to measure temperatures up to 1600C – which is 3x the previous generation.

Night Scene Mode

Clearer Details in Low-Light Environments

• NIR Auxillary Light:The camera view switches to black and white while the auxiliary light enhances illumination at the centre of the screen.

• Black and White Mode:The landscape appears in black and white, and infrared light can be used to illuminate the area below without causing excessive brightness.

• Full-Colour Mode:The IR filter that would typically cut out the infrared light is removed, allowing you to see a brighter landscape.

• Enhanced Noise Reduction:Quiet the background noise as you film.

• Laser-Assisted Focussing:By default, a laser rangefinder aids focusing.

• Night Scene Mode:With Night Scene mode and IR Light activated, the laser spot is visible at the centre of the black-and-white camera view.

H30T Visual And Zoom Cameras

Clearer Data from Afar

• Zoom Camera:The 1/1.8-inch 40MP zoom camera supports 34x optical zoom and 400x digital zoom.

• Wide-angle Camera:48MP 1/1.3-inch CMOS sensor, with 24mm equivalent focal length and 82.1 DFOV.

• Detailed Video:The wide and zoom cameras support a video resolution of 3840 x 2160 @ 30fps.

• Night-scene Mode:The wide and zoom cameras support night-scene mode.

• More Stable Imagery:Image stabilisation algorithms effectively diminish shake in telephoto footage captured by the zoom camera.

• Laser Rangefinder:Enhanced laser rangefinder with up to 3,000m maximum measuring distance – 2.5 times greater than the H20 Series. Real-time display of latitude and longitude coordinates and altitude.

H30T Smart Features

Intelligent Modes for Reliable Data Capture

• Storage-Friendly Bit Rate:Dynamically compress videos to save storage and CBR, maintaining a constant bit rate.

• Foreground Stabilisation:When videoing, foregrounds can be made the centre of focus for more accurate and reliable inspection data.

• Electronic Dehazing:Enhance footage quality with Electronic Dehazing, clarifying imagery from the zoom camera.

• Smart Track:Accurate tracking of moving objects through automated identification, positioning, and continuous tracking.

• AI Spot Check:The algorithm autonomously compares the target area with the real-time image to adjust the camera’s shooting angle, ensuring precise operations.

• H30T Flight Planning:Use Waypoints for precise mission planning or conduct emergency response mapping to locate and model routes.
