Description

SPECIFICATIONS

Use: Vehicles & Remote Control Toys

Upgrade Parts/Accessories: Adapter

Tool Supplies: Other

Technical parameters: KV1100

Size: 47*26.2*15mm

Remote Control Peripherals/Devices: Remote Controller

Recommend Age: 12+y,14+y

RC Parts & Accs: Connectors/Wiring

Origin: Mainland China

Model Number: Flysky FS-I6S

Material: Metal

Four-wheel Drive Attributes: Assemblage

For Vehicle Type: Airplanes

Brand Name: abay

Product description
The AFHDS 2A (Automatic Frequency Hopping Digital System Second Generation) developed and patented by Flysky is specially developed for all radio control models.Offering superior protection against interference while maintaining lower power consumption and high reliable receiver sensitivity,Flysky’s AFHDS technology is considered to be one of the leaders in the RC market today.

Features:FS-I6, FS-T6, upgraded version

Specifications:

• Remote Distance:1000M

• Band: 140

• Channels: 10

• Code type: GFSK

• Sensitivity: 4096

• Model type: Quadcopter

• RF Range: 2.4055-2.475GHz

• RF power: Less then 20dBm

• 2.4GHz system: AFHDS 2A

• DSC port: Micro USB , PPM

• Power input: 4.2V-6.0V

• Low voltage alarm: Yes (Lower than 4.2V)

• Weight: 410g

• FS-i6S Transmitter Size: 179mmx81mmx161mm

  IA6B Receiver

• Channels: 6

• Model Type: Fixed-Wing/Glider/Helicopter

• RF Range: 2.4055-2.475GHz

• RF Receiver Sensitivity: -105dBm

• 2.4GHz System: AFHDS 2A

• Modulation Type: GFSK

• Power: 4.0-6.5V DC

• Weight: 14.9g

• Size: 47*26.2*15mm

• i-BUS Port: Yes

• Data Acquisition Port: Yes

Package Mainly Include:

• 1 * FS-i6S Transmitter

• 1 * FS-iA6B Receiver

• FS-i6s phone holder mounting point SwB Swc VrA VrB SwA SwD left lever right lever neck strap power button USB port PS/2 port .
