KST X15-855X Mini Brushless Tail Servo

Description

The KST X15-855X Mini Tail Digital Metal Gear High Voltage Servo is a great choice for helicopters ranging from 430mm-570mm rotor blade size requiring mini tail servos such as the Align T-rex 500, Goblin 380/420 or Raw 420, OMP M4/M4 Max, Goosky RS4 … and others. Additionally these servos can be used in other RC applications where the physical dimensions, and torque/speed ratings suit the need of the RC application.

Features

• Hardened Steel Gears
• Extreme Torque and Excellent Speed
• CNC Aluminium Case
• Two Ball Bearings
• SupportHighVoltage8.4V
• Programmable via Programming Card

Specification

• Item: X15-855X Tail Servo
• Rated Voltage: DC7.4V
• Voltage Range: DC6.0V-8.4V
• Working Frequency: 760us/560Hz
• Temperature Range: -10+65
• Case Material: Aluminum Alloy
• Motor Type: Brushless DC Motor
• Gear Set Material: Hardened Steel
• Position Sensor: Potentiometer
• Ball Bearing: 2 Ball Bearings
• Case Dimensions: 35.5mm*15mm*35.5mm0.2mm
• Torque:[email protected], [email protected], [email protected]
• Speed: 0.07sec/[email protected], 0.06sec/[email protected], 0.05sec/[email protected]
• PWM Command Interface
• Weight:45g10%

Size

PackageIncluding

• 1 * X15-855X 8.4V for Helicopters Tail
• 1 * Accessories
