OMP Hobby 60" 70E Edge 540 Kevlar Reinforced Balsa 3D Airplane Receiver Ready Green

OMP Hobby 60″ 70E Edge 540 Kevlar Reinforced Balsa 3D Airplane Receiver Ready Green

Original price was: $66.00.Current price is: $33.00.

SKU: TNGZ263923259 Category:

Description

Parameter Specification

Item OMPHOBBY 60EDGE 540 Color: Green Red Yellow Orange
Wing Span: 1524mm(60in) Full Length: 1500mm(59in)
Flight Weight: 2.75~2.85KG The Center of Gravity (CG) Approx.86-95mm
Wing Area: 42.32d Wing Load: 64.98~67.34g/d
Wing Angle of Incidence: 0 Motor Thrust Angles: Down 0 & Right 2.8
Pack Dimension 130*44*22 (L*H*W)cm Gross Weight: 10KG
Servo: 13~15 Kg.cm*4 (Aileron*2,Elevator*1, Rudder*1) , Servo Arm: 1.25″ 25T Servo Arm
Electric Power (Recommended):

Option 1: Motor: X4120 550KV ESC: 80-100A Propeller: Eolo 15×8 Lipos: 6s 3300mah-4000mah

Option2: Motor: 4125 515KV Esc 100A Propeller: Eolo 16×8 Lipos: 6s 3300mah-4000mah


Recommended Settings of Dual Rates and Exponentials of Control Surfaces

Rate EXP Direction Throw
Aileron High 35~40% Up 36~39
Low 40~45% Down 20~26
Elevator High 38~45% Up 45~53
Low 45~55% Down 30~35
Rudder High 38~45% Up 42~50
Low 45~55% Down 28~32
