SANWA EXZES ZZ Stick Radio Set with RX- 472 AS NEW NO BOX

Description

THE FASTEST RESPONSE OF M12S IS PORTED!
YOU CAN GET THE FASTEST RESPONSE WHICH
HAS ACHIEVED THE TRIUMPHS IN WORLD CHAMPIONSHIPS.

NOT ONLY HIGH RESPONSE BUT ALSO EXCELLENT LINEAR MOVEMENT
INCREASE THE DRIVING STABILITY IN THE FINAL MATCH.
HAVING NO EQUAL TO OTHER MODELS.

SYSTEM: 2.4GHz Computer System FH4/FH3CH: 4CHTRANSMITTER: TX-452RECEIVER: RX472

[NEW FEATURES]
Telemetry Mixing Template Vibrator Mode Select Throttle Slow Life-Battery Compatible Earphone Jack
Ackerman Steering Racing Mode (Enhanced) Timer/Alarm (Enhanced) CODE10/Telemetry Assignment
CODE AUX NAMING

[OTHER FEATURES]
FSTN Large full dot LCD (128×256) Menu Selector ST, TH Spring adjustment Logger
Feeling PC Link Monitoring Racing Mode Car Type Select CODE AUX
Cross Movement Function System Bind Model Memory(50 models) Model Name(14 letters)
LCD Contrast RF Mode Setting (FH4/FH3) Response Mode Setting(NOR/SHR/SSR)
Model(Select/Copy/Clear/Sort) Vibrator Key Assignment (SW/TRIM/DIAL/LEVER)
Buzzer(Selectable Scale/Volume) AUX Type Setting (AUX/AUX1/AUX2) Point AUX
MOA AUX 4WS AUX Trim Type(Center/Parallel) User Name(14 letters) Information
Log(REC/RPM/VOLT/TEMP1/TEMP2/ST POINT/TH POINT/RX MODE) Battery Alarm
EPA Trim/Sub Trim Servo Reverse Fail Safe (Radio Wave/Battery) Boost Menu
Timer(Lap/Interval 1/Interval 2) Dual Rate(ST/TH/BR) Curve(EXP/ARC/CRV) Point Curve
SPEED Anti-Lock Brake Brake Mixing TH Hold Ackerman Steering Compensation Mixing
(C-MIX1/C-MIX2) Safety Link Direct Model Select Language Customized menu Throttle Type
Offset CH Set Calibration: Ex-Volume Adjustment (ST/TH/LEVER)
Compatible Receivers: RX-482, RX-481, RX-472, RX-471 Dual-ID, RX-471W, RX-471, RX-462,
RX-461, RX-451R, RX-451, RX-381, RX-380

[SSL(SANWA Synchronized Link) Sysytem]
SANWA NEW SSL SYSTEM
When used with compatible RX-472, RX-482, Super Vortex Series, SV-Plus Series, the setting of ESC etc. by Transmitter is available through SSL functions while driving.
Since the setting can be done without the stop of car, the detailed adjustment in accordance with Race conditions
is available without interruption of Intervals and the change of machine conditions.
[Response of Telemetry System]
It is often said that telemetry system reduce response speed. However, SANWA Original Data Processing and Algorithm Design makes Telemetry possible without response speed reduction.
Our Excellent Telemetry System has no response speed reduction.
With our telemetry system, the precious race data will help the next race setting and driving.
[Response Mode]
Please do not use Analog Servo for SHR mode or SSR mode.
If analog servo is used for SHR mode or SSR mode, the servo will be broken and will not work.
Digital servo (SRG series, Digital ERG series, SDX series) can be used both for NOR mode and SHR mode.
SSR mode can be used only by SRG series servo.
In SHR or SSR mode, BL-RACER, BL-FORCE, BL-SPORT, F2000, F2200, F3000, F3300, SBL-01, SBL-02 and SBL-03CR do not work. Please make sure to use NOR Mode for them.
SV-08, HV-10, HV-12, F2500 can be used for both NOR and SHR Mode.
Please use NOR mode for the above ESC.

[System Programming]
PC-LINK MANAGER3 for M12S/EXZES ZZ Application Manual(PDF)
PC-LINK MANAGER3 for M12S/EXZES ZZ Application Software(zip)
*Only for M12S / EXZES ZZ
Please use PC-LINK MANAGER2 for M12/EXZES Z

Programming Version Upgrade for EXZES ZZ(Standard)v401205(zip)
The above upgrade is only for EXZES ZZ.
M12S or M12 or Exzes Z cannot be upgraded.
