Sale!
T-Motor AT4125 VTOL Fixed Wing Aircraft Long Shaft Motor KV540
Original price was: $126.00.$63.00Current price is: $63.00.
Description
| Parameter | Specification |
|---|---|
| Product Name | AT4125 Long Shaft Fixed-Wing Brushless Motor |
| Motor Type | Brushless Outrunner Motor |
| Intended Use | Fixed-wing aircraft / VTOL UAV propulsion |
| KV Ratings Available | 540 KV |
| Supported Battery | 6S |
| Rated Voltage | 22.2V |
| Maximum Power (180 s) | ~2,200 W |
| Peak Current (180 s) | ~85 A |
| Idle Current (10 V) | ~2,6 A |
| Stator Configuration | 12N14P |
| Shaft Diameter | ~6 mm |
| Weight (with cables) | ~355 g |
| Motor Dimensions | ~50 74 mm |
| Magnet Type | High-strength rare-earth magnets |
| Typical Propeller Range | ~158 class (build dependent) |
| Primary Applications | Fixed-wing UAVs, VTOL aircraft, heavy-lift platforms |
