TLIBOT FCD-C 14, Ratios 50/80/100, 5.2 Nm Rated Torque, 8500 r/min Input, Robot Motor for Robotics

TLIBOT FCD-C 14, Ratios 50/80/100, 5.2 Nm Rated Torque, 8500 r/min Input, Robot Motor for Robotics

Original price was: $145.00.Current price is: $72.50.

SKU: BVHB1865361360 Category:

Description

Overview

TLIBOT FCD-C is a Robot Motor platform in size 14 with selectable reduction ratios of 50, 80, and 100. It delivers rated output torque up to 5.2 Nm at 2000 r/min input with compact inertia, making it suitable for precise robotic joints and mobile platforms.

Key Features

  • Model 14 robot motor with three reduction ratios: 50 / 80 / 100.
  • Rated torque at 2000 r/min input: up to 5.2 Nm (0.53 kgfm).
  • Allowable peak torque at start/stop: up to 19 Nm (1.9 kgfm).
  • Instantaneous maximum allowable torque: up to 35 Nm (3.6 kgfm).
  • Maximum allowable input speed: 8500 r/min; allowable average input speed: 3500 r/min.
  • Low rotor inertia values provided for precise control.

For quotations or technical support, contact [email protected] or visit https://rcdrone.top/.

Specifications

Parameter 50 80 100
Model 14 14 14
Rated Torque at 2000 r/min Input (Nm) 3.6 5.2 5.2
Rated Torque at 2000 r/min Input (kgfm) 0.37 0.53 0.53
Allowable Peak Torque at Start and Stop (Nm) 12 16 19
Allowable Peak Torque at Start and Stop (kgfm) 1.2 1.6 1.9
Allowable Maximum Value of Average Load Torque (Nm) 4.8 7.7 7.7
Allowable Maximum Value of Average Load Torque (kgfm) 0.5 0.8 0.8
Instantaneous Maximum Allowable Torque (Nm) 24 35 35
Instantaneous Maximum Allowable Torque (kgfm) 2.4 3.6 3.6
Maximum Allowable Input Speed (r/min) 8500 8500 8500
Allowable Average Input Speed (r/min) 3500 3500 3500
Moment of Inertia (I x 10^-4 kgm^2) 0.021 0.021 0.021
Moment of Inertia (J x 10^-5 kgm^2) 0.021 0.021 0.021

Applications

  • Humanoid robots
  • Robotic arms
  • Exoskeletons
  • Quadruped robots
  • AGV vehicles
  • ARU robots

Manuals

  • FCD-14-XXX-C Product structure diagram (PDF)
  • FCD-17-XXX-C Product structure diagram (PDF)
  • FCD-20-XXX-C Product structure diagram (PDF)
  • FCD-25-XXX-C Product structure diagram (PDF)
  • FCD-32-XXX-C Product structure diagram (PDF)
  • FCD-40-XXX-C Product structure diagram (PDF)
  • WK8110_2D_drawing.pdf
  • FCD-C 3D Model STEP (ZIP)

Details

TLIBOT Harmonic Reducer, precision transmission, 15 years expertise, 3-100 models, full customization, complete service.

Technical specifications of Tlibot Fcd-C14 robot motor, including reduction ratios, torque values, speed limits, and moment of inertia for various models from 14 to 50.

Products include various models: 3, 5, 8, 11, 14, 17, 20, 25, 32, 40, 45, 50, 58, 65, 100. Reduction ratios: 30, 50, 80, 100, 120, 160, 320 and more. Multiple motor designs are displayed.
