XF C-40T 3-Axis Gimbal, 40 g Payload, +/-0.05 Accuracy, 7.4 ~ 26.4 VDC, UART/MAVLink/S.BUS/CRSF/PWM

XF C-40T 3-Axis Gimbal, 40 g Payload, +/-0.05 Accuracy, 7.4 ~ 26.4 VDC, UART/MAVLink/S.BUS/CRSF/PWM

Original price was: $179.00.Current price is: $89.50.

SKU: BVHB1865361176 Category:

Description

Overview

The XF C-40T 3-Axis Gimbal is a compact, nonorthogonal mechanical stabilization 3-axis gimbal designed for payload devices up to 40 g. High-torque motors and the 3-axis structure deliver strong stabilization against vibration and high-speed air impact. With Headtracker support, it enables an immersive first-person control experience.

Key Features

  • 3-axis nonorthogonal mechanical stabilization with high-torque motors
  • Supports payload devices up to 40 g
  • Angular accuracy: +/-0.05
  • Max rotation speed: +/-1500/s
  • Wide operating voltage: 7.4 ~ 26.4 VDC
  • Mounting options: downward / upward
  • Control ports: Headtracker / UART (private protocol & MAVLink) / S.BUS / CRSF / PWM
  • Wire-through aperture: 4.2 mm

For sales or technical support, contact https://rcdrone.top/ or [email protected].

Specifications

Product Name C-40T
Dimensions (with damper) 55.5 x 53 x 66 mm
Weight (with damper) 58 g
Operating Voltage 7.4 ~ 26.4 VDC
Power 3 W (AVG) / 18 W (Stall)
Mounting Downward / Upward
Control Port Headtracker / UART (private protocol & MAVLink) / S.BUS / CRSF / PWM
Wire-through Aperture 4.2 mm
Gimbal Type 3-axis Nonorthogonal Mechanical Stabilization
Angular Accuracy +/-0.05
Controllable Range Pitch: -110 to +145, Roll: +/-45, Yaw: +/-145
Max Rotation Speed +/-1500/s
Maximum Payload Weight 40 g

Manuals and Downloads

Release and Upgrade

  • C-40T Release and Upgrade Records (2025-07-07): pdf

Software and Firmware

  • C-20_Upgrade_Package_V3.8 (2025-07-07): rar
  • Gimbal Private Protocol Assistant (2025-07-10): rar

Document

  • C-40T 3-Axis Gimbal Specifications (2025-09-05): pdf
  • C-40T 3-axis Gimbal User Manual-XF(A5)V1.1 (2025-08-06): pdf
  • Gimbal Private Protocol-XF(A5)V1.0.3 (2025-07-07): pdf

Blueprint

  • C-40T_Simplified Model (2025-11-26): stp
