Zoom MicTrak Stereo Shotgun Microphone and Recorder Refurbished

Description

Zoom M3 MicTrak – The First Shotgun Mic With 32-Bit Float Recording

Picture perfect sound in one take. The M3 MicTrak gives filmmakers the ability to elevate their content with pristine audio. This on-camera stereo microphone / recorder captures every sonic nuance with 32-bit float recording.

Product Highlights:

Stereo Shotgun Microphone with 90 degree, 120 degree, and MONO

Built in 32-bit float recorder

Records additional Mid-Side RAW file for post-production stereo adjustment

Includes custom Zoom Shock Mount

Lo cut filter

Camera mounted or grip mounted

3.5mm stereo line output for camera connection

3.5mm headphone output

Companion Edit & Play software to adjust stereo width and normalize recorded files

Records to SDXC cards

USB Microphone compatible with PC and Mac

Runs on 2 AA batteries (12 hour battery life)

Product Features:

32-Bit Float Recording

The M3 captures clip-free audio, every time. With 32-bit float recording, there’s no need to set gain. Whether its dialogue, sound effects or outdoor ambience, youll always get the perfect take.

Run-And-Gun Ready

Quickly shift from scene to scene with the M3 attached to the camera of your choice. Its specially designed shock mount keeps your setup lightweight and ensures minimal handling noise.

Stereo & Mono Modes

Easily switch between mono and stereo modes. Mono mode is optimal for capturing dialogue. 90 gives an accurate, transparent stereo capture. 120 provides a generous stereo capture ideal for ambience or sound effects.

More Flexibility In Post

The M3 always saves a backup Mid-Side RAW file, giving you the flexibility to adjust the stereo width of your recording in post.

Backup Your Recording

Use the M3s 3.5mm stereo output to connect to your camera and record a backup. This is especially helpful when syncing your audio to video.

Streamlining Post Production

With the M3 Edit and Play software, you can adjust the stereo width of your recording and normalize your files to prepare them for syncing and editing.

USB Microphone

Connect the USB-C port to a PC, Mac, iOS, or Android device to use the M3 as a USB mic for streaming or recording.

Monitor & Playback

Use the 3.5mm headphone output to monitor your recording.

For All-Day Shoots

With SDXC card support up to 1TB and 12-hour AA battery life, the M3 can keep your sound powered during long production days.

Product Specifications:

Inputs

Mid Mic (Mono shotgun):

Directionality: Super cardioid

Input Gain: Adjustment unnecessary (dual A/D converter circuit used)

Maximum Sound Pressure Input: 133 dB SPL

Side Mic:

Directionality: Bidirectional

Input Gain: Adjustment unnecessary (dual A/D converter circuit used)

Maximum Sound Pressure Input: 119 dB SPL

Outputs

Line Out:

Connector: 3.5 mm stereo mini jack

Maximum Output Level: +1.2 dBu (into 2 k load)

Output Impedance: 100

Phone Out:

Connector: 3.5 mm stereo mini jack

Maximum Output Level: 20 mW + 20 mW (into 32 load)

Output Impedance: 10

Recorder

Maximum Simultaneous Recording Tracks: 4

Maximum Simultaneous Playback Tracks: 2

Recording Format:

WAV

48 kHz, 32-bit float stereo

BWF format supported

Recording Media:

4-32GB cards compatible with the microSDHC specification

64GB-1TB cards compatible with the microSDXC specification

USB

Connector: USB Type-C – Use a USB cable that supports data transfer

USB Mic:

USB 2.0 High Speed

48 kHz, 24-bit

2-in/2-out

File Transfer: USB 2.0 High Speed

Power

2 AA Batteries: Alkaline, Lithium, or Rechargeable NiMH

AC Adapter:

ZOOM AD-17: DC 5 V/1 A

USB bus power is supported

Estimated Continuous Operation Time Using Batteries:

Alkaline Batteries: About 12 hours

NiMH Batteries (1900 mAh): About 11 hours

Lithium Batteries: About 21 hours

Rated Current:

Batteries: 234 mA

USB Bus Power / DC 5V Power Supply: 186 mA

Power Consumption: 1.5 W maximum

General

Dimensions: 2.82″W (71.6 mm) x 7.93″D (201.3 mm) x 1.5″H (38 mm)

Weight (including batteries): 0.3 lbs (135 g)

Note: 0 dBu = 0.775 Vrms
