Futaba T6K V3S Transmitter – 8 Channel 2.4GHz S-FHSS/T-FHSS Radio System With R3006SB / R3008SB Receiver

Description

Overview

The Futaba 6K V3S Transmitter is a robust and versatile 8-channel digital proportional RC system, leveraging advanced 2.4GHz T-FHSS/S-FHSS wireless technology to deliver exceptional signal stability and reliability. Whether you are a seasoned pilot or a hobbyist, the 6K V3S meets high standards for control precision and multifunctionality, making it ideal for fixed-wing aircraft, helicopters, gliders, and multi-rotor drones.

Features

• Dual Stick Design with 8-Channel Control
  Featuring a 2-stick configuration, the transmitter offers intuitive and precise control, suitable for a wide range of aircraft types including fixed-wing, helicopters, gliders, and multi-rotors.

• Advanced Wireless Systems
  Supports both T-FHSS Air and S-FHSS modes with an RF output power of up to 100mW EIRP, ensuring stable signal transmission even during long-distance flights.

• Dual Receiver Compatibility
  Comes with either the R3006SB (6-channel) or R3008SB (8-channel) receiver, catering to various model requirements.

• Comprehensive Telemetry Functions (T-FHSS Only)
  Utilizes a bidirectional T-FHSS Air communication system to monitor critical flight data such as battery voltage, altitude, temperature, RPM, current, and voltage in real-time via optional telemetry sensors installed on the aircraft.

• Speech Function (T-FHSS Only)
  Allows real-time audio feedback of telemetry data by plugging commercial earphones into the transmitter, enhancing situational awareness during flight.

• Built-In Antenna Design
  Integrated antenna provides a sleek appearance and improves handling ease, eliminating the need for external antennas.

• S.Bus/S.Bus2 Servo Configuration
  Supports S.Bus and S.Bus2 servo channels, allowing for easy programming and configuration of various functions directly through the transmitter.

• Power-Saving Design
  Operates on four AA alkaline batteries or compatible alternatives such as NiMH or lithium-ferrite batteries, extending usage time and reducing power consumption.

• Vibration Alerts
  Features vibration alerts for various alarms, ensuring that the pilot is promptly notified of important status changes.

• 30-Model Memory
  Stores up to 30 different models with 8-character naming for both models and users, facilitating efficient management of multiple setups.

• Multiple Mixing Types
  Selectable mixing types for fixed-wing, helicopter, glider, and multi-rotor configurations, including six swash plate types for helicopters and expanded multicopter flight modes.

• Digital Trim
  Enables rapid trimming during flight with adjustable step sizes and on-screen display of trim positions on the LCD.

• Adjustable Stick Length and Tension
  Customizable stick lengths and anti-slip designs enhance comfort and precision during operation.

• Flexible Switch/VR Position and AUX Channel Functions
  Programmable switches and AUX channels allow for personalized mixing and function assignments, supporting original and advanced mixing setups.

• Wireless Model Data Transfer
  Facilitates easy wireless transfer of model data between 6K series transmitters, streamlining the setup process.

• Backlit LCD Screen
  128×64 DOT backlit display with adjustable contrast for clear visibility in various lighting conditions.

• Software Updateable
  Easily updateable through the CIU-2 interface to ensure the transmitter remains up-to-date with the latest features and improvements.

• Multiple Connectivity Options
  Includes earphone, S.Bus, and Trainer jacks for versatile connectivity.

• Assignable Switches
  Three 3-position switches and one 2-position switch for customizable control options.

• Range Check
  Verify the operational range before flights to ensure safety and reliability.

• Program Navigation Bay
  Equipped with jog dial, +/- pads, and end pad for easy menu navigation.

• Data Management
  Features data reset, model copy, and selectable model types for efficient data handling.

• Safety Features
  Includes fail-safe settings, end points, trim adjustments, sub trims, servo reversing, and parameter functions to enhance safety and control.

• Servo Monitor/Test
  Allows for real-time monitoring and testing of servo performance.

• Trainer System
  Supports training modes for novice pilots to practice without risking their main model.

Specifications

Transmitter Specifications

• Frequency: 2.4 GHz Band
• System: T-FHSS Air, S-FHSS (switchable)
• Power Supply: 6.0 V Dry Battery
• RF Power Output: 100mW EIRP
• Memory: 30 Model Slots
• LCD Screen: 128×64 DOT Backlit, Adjustable Contrast
• Dimensions: 17 10 5 in (432 254 127 mm)
• Weight: 1814 g
• Version: Hobby Version
• Supported Models: Air, Heli

Receiver Specifications

• Models: R3006SB / R3008SB
• Size: 25 x 43.1 x 8.8 mm (0.98 x 1.7 x 0.35 in)
• Weight: 8.5 g (0.3 oz)
• Rated Voltage: DC 4.8~7.4V
• Operating Voltage: DC 4.0~8.4V

Included in the Package

• Futaba 6K-V3S 8-Channel Transmitter
• R3008SB 8-Channel Receiver
• Note: Batteries are not included.
  • Requires: Four (4) AA size batteries (recommended: Admiral NiMH AA Rechargeable Batteries, 4 Pack)
  • Optional: 6V NiMH or 6.6V LiFe batteries

Brand Advantage

Founded in Japan in 1948, Futaba has built a legacy of over 74 years in RC technology and innovation. With a workforce of over 5,000 international employees and hundreds of thousands of products delivered worldwide, Futaba continues to lead the industry with reliable and cutting-edge remote control solutions. Trust in Futaba to provide the best performance and quality for all your RC needs.

Futaba T6K V3S Transmitter: High-performance transmitter with advanced features and ergonomic design for precise control.

Futaba T6K V3S Transmitter for RC drones and planes with advanced features and high-quality build.

Futaba T6K V3S Transmitter Propo Digital Air Radio Control System for RC Models

Futaba T6K V3S Transmitter for Airplanes and Helicopters

Futaba T6K V3S Transmitter: 8-Channel Digital Proportional Radio Control System with 2GHz T-FHSS, Air Tek 6 Telemetry System and 24GHz T-FHSS IQ Frequency Hopping Spread Spectrum. Features include telemetry system, SLink, RODEL-01 Futaba FHSS backlit LCD screen, earphone jack, throttle cut, glider-wire function, fail-safe, multicopter function, timer, and more.

Futaba T6K +R3006SB Review
