(Motor+ESC+Remote) DIY Electric skateboard longboard kit 100A VESC based Speed Controller and brushless Red cover motor (non-sealed motor) and remote

(Motor+ESC+Remote) DIY Electric skateboard longboard kit 100A VESC based Speed Controller and brushless Red cover motor (non-sealed motor) and remote

Original price was: $15.00.Current price is: $9.00.

SKU: UVXZ746841890953 Category:

Description

(Motor+ESC+Remote) DIY Electric skateboard longboard kit 100A VESC based Speed Controller and brushless Red cover motor (non-sealed motor) and remote

Price includes 1pcs ESC and 1pcs motor and 1pcs Remote

1.Specifications of VESC100A 100A ESC based on VESC speed controller:

Application electric skateboard longboard fighting robots combat robots
BEC 5V BEC
Lipo 3-12Cells
Voltage 8V-60V
Hardware version based on 4.12
Firmware version 3.40
Cont. Current 100A
Burst Current 280A
Capacitors With high quality aluminum case, better heat dissipation
Case Size 71.5mm(L)x45.8mm(W)x18mm(H)
Power wire Silicon wire
Accessory USB programming cable

Features:
With 4.0mm golden connectors for motors, without connector for battery.
With high quality aluminum case, better heat dissipation
Dustproof and splashproof
Compatible with sensor or sensorless motor
Sensored or Sensorless operation
Great startup torque with sensorless motors
Softswitching to reduce the losses in power electronic switches
Separation of low power electronics from the high power electronics, make it more reliable.
2.Motor specifications

Model No.

MTO6355-190-HA

MTO6365-200-HA

MTO6374-190-HA

With Hall Sensor

With Hall Sensor

With Hall Sensor

KV

190

200

190

Idle Current

1.0A

0.8A

0.8A

Max. Current

65A

65A

65A

Input Volt

2-12s Lipo

2-12s Lipo

2-12s Lipo

Max. Output Watt

3510W

3520W

3550W

Max. Pull

12000g

9700g

13000g

Rated Current

55A

60A

60A

Motor Weight

600g

745g

825g

Shaft

8mm

8mm

8mm

Output shaft length

26mm

26mm

26mm

Resistance

0.0441

0.0402

0.0402

3.Specification of MTSKR20WFV2 waterproof Remote controller with screen and receiver:

Model No. MTSKR2005WF (MTSKR20WFV2) Waterproof Rank IP66
Control Mode New Esk8 Application Only for Electric skateboard, elongboard, mountainboard
Speed Display Yes Travel Mileage Yes
Throttle and brake Display 100% VESC Control Mode Duty Cycle/ Current Mode
Speed Mode

3 speed modes, each mode can adjust speed from 1%-100% throttle

 Accessories Wireless charging pad; receiver; 3pcs dupont cable
Charger

QC 2.0 wireless

 Wireless Frequency 2.4GHz wireless with 40 channels
Display Screen

OLED yellow & blue screen

 Triggers 2x high senstive triggers
Throttle and Brake Signal Output Range

1.5ms-2ms for throttle;

1.5ms-1ms for brake

 Telemeter Data by Receiver Motor RPM; main battery voltage
Voltage Display

Remote & main battery voltage level (lithium iron; lithium ion battery optional)

 Telemeter Data by VESC ESC voltage/ current/ temp; Motor temp/ RPM
Compatible ESCs

VESCTOOL/ Focbox/ Other PWM ESCs that has same signal output range with the remote

 Receiver Built-in Switch for Esk8 Light / Esurf Water Pump

1x 30V 3A mechanical relay switch;

1x 20V 2A transistor electronic switch
