TOPOTEK TP18 Drone Camer Gimbal - 18 Optical Zoom Camera 3-Axis Gimbal HDMI Output

TOPOTEK TP18 Drone Camer Gimbal – 18 Optical Zoom Camera 3-Axis Gimbal HDMI Output

Original price was: $1,599.00.Current price is: $148.00.

SKU: BVHB1865365163 Category:

Description

TOPOTEK TP18 is a UAV load system that integrates an 18x optical zoom camera and a 3-axis HDMI output gimbal. The MINI HDMI interface outputs 1080P 60FPS high-definition video, supporting gimbal control and zoom camera control. The gimbal uses a high-precision encoder FOC control scheme, which is characterized by high stability, small size, light weight, and low power consumption. The camera uses a low-illumination sensor with an effective pixel of 4 million, supporting 1080P local TF storage. Built-in camera core TOP-3082.

TOPOTEK TP18 Advantages

  • 18x optical zoom, TF record
  • 1080P HDMI output
  • 3-axis stabilizer
  • PWM, SBUS, UART control
  • OSD menu
  • Support angle and speed reading & setting

TOPOTEK TP18 Specifications

Voltage 3S or 6S
Power 3.12W
Technical Parameters
Roll Angle -85 ~ +85
Pitch Angle -90 ~ +90
Yaw Angle -150 ~ +150
Jitter Angle 0.02
Horizontal Jitter Angle 0.03
One-Click Restore One-click restore to the initial position
Adjustable Gimbal Speed Use low speed control at big zoom status for high precision display. Use fast speed control at small zoom status
Daylight Sensor Parameters
CMOS Size 1/3 4M Pixels CMOS sensor
Zoom 18x HD optical zoom lens, f=4.510%~13510%mm
Focus Focus in real time, less than 2 secs
Video Output HDMI output 1080P/720P, TF card recording
Field of Vision (FOV) D : WIDE 67.8 5% TELE 2.77 5%
H : WIDE 59.8 5% TELE 2.34 5%
V : WIDE 40.5 5% TELE 1.48 5%
Video Mode 1080P 60fps (can be set as 1080P 30FPS)
Gimbal Size 160mm x 102mm x 140mm
Working Condition -10C to +45C / 20% to 80% RH
Storage Environment -20C to +60C / 20% to 95% RH
Weight 600 20 gram

Enjoy the benefits of this drone camera’s 18x optical zoom, TF card recording, PWM and SBUS control, UART setting, 1080P HDMI output with on-screen display menu, and 3-axis stabilizer for smooth footage capture.
